Manufacture ASTM B760 W1 Tungsten plate sheet reasonable price

group name: TUNGSTEN PLATE

Min Order: 1 kilogram

brand name: GETWICK 東吉

model: W1

Nearest port for product export: Shanghai,, Guangzhou, Qingdao, Tianjin

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DDP, DDU, Express Delivery

Acceptable payment methods: T/T, L/C, D/P D/A, Credit Card, PayPal, Westem Union, Cash, Escrow

update time: Mon, 08 Apr 2019 16:45:30 GMT

contact supplier

Paramtents

Material Tungsten
Purity 99.95% min.
Standard ASTM B760
Grade W1
Shape tungsten sheet, tungsten plate
Working temperature above 2000Dc
MOQ 1kg
Surface black, chemical cleaning, polished
Feature high temperature resistance
Products Name GETWICK W1 New Product Tungsten Sheet/Plate Price

Packging & Delivery

Min Order1 kilogram

Briefing

GETWICK 99.95% pure w1 tungsten sheet for sale
99.95% Polished good quality Tungsten plate for industry

Detailed

manufacture ASTM B760 W1 Tungsten plate sheet reasonable price

1.Applications:
* For producing electric light source parts,components of electric vacuum;
* For producing W-boats,heat shield and heat bodies in high temperature furnace.

2.Size: 0.05mm min.( Thickness ) x 400mm max.( Width ) x 1000mm max.( Length )

3.Purity: 99.95%min.
4.Standard: ASTM B760 or GB3875-83

5.ASTM B760 as follows:

Chemical composition
element	Max
C	0.01
O	0.01
N	0.01
Fe	0.01
Ni	0.01
Si	0.01

6.Surface: shiny, alkaline washed, satin, or as-rolled condition; dependent upon thickness and width parameters.

Normal specification we can provide:

Tungsten Plate/Sheet /Foil
Thickness(min) mm	Width(max) mm	Length(max) mm
0.05	150	500
0.06~0.09	250	500
0.1	300	500
0.12	320	550
0.15	350	600
0.2~0.6	400	600
0.7~0.9	400	800
1~2	450	800
2~10	450	600
10~15	450	500
15~25	300	500

7.Our products is available in a wide range of forms including nut, screw ,ring ,wire, foil, sheet,rod, strip, plate, tube, alloys according to Standard ASTM AMS ASME MIL DMS JIS GB, etc.

8.If you have any needing or question ,pls tell me and i would like you try my best to help you.Looking forward to hearing from you.
