GETWICK 99.95% high temperature w1 tungsten plate sheet for sale

group name: TUNGSTEN PLATE

Min Order: 1 kilogram

brand name: GETWICK 東吉

model: W1

Nearest port for product export: Shanghai,, Guangzhou, Qingdao, Tianjin

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DDP, DDU, Express Delivery

Acceptable payment methods: T/T, L/C, D/P D/A, Credit Card, PayPal, Westem Union, Cash, Escrow

update time: Mon, 08 Apr 2019 16:45:30 GMT

contact supplier

Paramtents

Material Tungsten
Purity 99.95% min.
Standard ASTM B760
Grade W1
Shape tungsten sheet, tungsten plate
Working temperature above 2000Dc
MOQ 1kg
Surface black, chemical cleaning, polished
Feature high temperature resistance
Products Name Getwick High Pure Polished Tungsten Plate 8mm Pric

Packging & Delivery

Min Order1 kilogram

Briefing

High quality 19.3g/cm3 99.95% Tungsten plate sheet price
99.95% Polished good quality Tungsten plate for industry

Detailed

GETWICK 99.95% high temperature w1 tungsten plate sheet for sale

1.Grade: W1

2.Size:0.05mm min.( Thickness ) x 400mm max.( Width ) x 1000mm max.( Length )

3.Purity: 99.95%~99.97%
4.Standard: ASTM B760

Tungsten Plate/Sheet /Foil
Thickness(min) mm	Width(max) mm	Length(max) mm
0.05	150	500
0.06~0.09	250	500
0.1	300	500
0.12	320	550
0.15	350	600
0.2~0.6	400	600
0.7~0.9	400	800
1~2	450	800
2~10	450	600
10~15	450	500
15~25	300	500

5.ASTM B760 as follows:

Chemical composition
element	Max
C	0.01
O	0.01
N	0.01
Fe	0.01
Ni	0.01
Si	0.01

6.Thickness Tolerance

Standard Width inch (mm)	Standard Thickness inch(mm)	Thickness Tolerance inch (mm)
≤12(305)	0.001-0.010 (0.05-0.25)	±0.001(±0.0254)
	>0.010-0.020 (0.25-0.51)	±0.002(±0.0508)
	>0.20(0.51)	±10%
>12-24(305-610)	>0.010-0.025(0.25-0.64)	±0.0025(±0.0635)
	>0.025(0.64)	±10%

Features:
1.Tungsten sheet adopts the material tungsten with a high purity of 99.9%;
2.Surface of tungsten sheet has metallic silver luster;
3.Its radiation shielding effect is equivalent to that of lead plate;
4.The density of tungsten sheet is higher than 19.1g/cm3;
5.Our tungsten sheet can be as thin as 0.05mm ;
6.Tungsten sheet from Achemetal is under vacuum annealing and leveling before delivery;
7.Our tungsten sheet is approved by ASTM B 386-2003 and GB 3876-2007 and GB 3877-2006.

Application:

1.Metallurgy industry, chemical industry, machinery industry, Medical ;

2.Electronics technology industry source technology industry;

3.Electric light source parts,heat shield;

4.Tungsten boat, high temperature furnace;

5.Computer, communications technology, optical materials, medicine;

6.Aerospace development, new energy materials, photosensitive material and

catalyst materials

GETWICK 99.95% tungsten plate and tungsten sheet
